Wacom

Wacom Cintiq Pro 24 Pen Display

Product no.:

Manufacturer no.:

Application: Design - Display size: 59.9 cm (23.6") - Colour display: Yes - Pen pressure levels: 8,192 - Physical resolution: 3840 x 2160 4K UHD... more

To see prices, log in or register an account.

Expected delivery on 20. August. Larger orders may incur extended delivery times.

Only a few items left in stock.

Draw and write directly on screen with the most natural pen experience Video input: USB Type-C port (supports DisplayPort Alternate Mode) or DisplayPort or HDMI 2.0 port (required for 3840 x 2160 resolution) Connect to any Mac or PC with a single USB-C cable (included) to a USB-C port for both video and data. DisplayPort or HDMI are also included, which require USB port for data. Stylus: Battery-free Wacom Pro Pen with 2 customisable side switches and 8192 levels of pressure sensitivity forpen nib and eraser. Ergonomics: Integrated pop-out legs for 20° angle (5° angle without legs); optional rotating Wacom Ergo Stand System requirements: PC: Windows 7 or later Mac: OS X 10.11 or later Includes: Wacom Pro Pen 2 with 4-colour pen ring set ExpressKey remote (with USB-A RF dongle and 30 cm Micro USB to USB charger cable) Pen stand with 10 replacement nibs (6 standard, 4 felt) and nib removal tool Pen holder AC adapter (180 W) Power cable (1.8 m) USB-C to USB-C cable (1.5 m) DisplayPort to DisplayPort cable (3 m) HDMI 2.0 to HDMI 2.0 cable (3 m) Standard USB-A to USB-A cable (3 m) DisplayPort to Mini DisplayPort adapter Quick start guide Regulation sheet Cleaning cloth

Wacom Cintiq Pro 24 Pen Display

Product
Product typePen display
Manufacturer’s warranty2-year bring-in (see manufacturer's website for details)
Display
Display size59.9 cm (23.6")
Colour displayYes
Physical resolution3840 x 2160 4K UHD
Aspect ratio16:9
Contrast1000:1
Brightness350 cd/m²
Viewing angle (horizontal / vertical)176° / 176°
Response time12 ms
Optical properties
Pen pressure levels8,192
General
ApplicationDesign
FeaturesCustomisable ExpressKeys, On-screen keyboard, Display toggle, Adjustable stand, ExpressKey remote, Precision mode, Radial menu, Touch Ring, Dedicated pan, scroll, zoom, brush size, Time-saving settings
Design
ColourBlack
Connectivity
Connectors1 x HDMI, 1 x 3.5 mm audio female, 1 x USB Type-C, 1 x DisplayPort, 2 x USB Type-A, 4 x USB 3.0 Type-A
Sustainability
Energy efficiency classG
Energy efficiency class rangeA - G
Energy consumption29 kWh / 1000 h
Security
SecurityKensington standard slot
Special features
Special featuresBuilt-in microphone, SD card slot
Physical properties
Dimensions (W x H x D)677 x 394 x 47 mm
Weight7.0 kg
Version
VersionUnited Kingdom

Datasheets

Wacom Cintiq Pro 24 Pen Display - Data sheet 1

File type: PDF

File size: 724 KB

Wacom Cintiq Pro 24 Pen Display - Product data sheet on energy consumption

File type: PDF

File size: 44.09 KB

Sustainability
Energy efficiency classG
Energy efficiency class rangeA - G
Energy consumption29 kWh / 1000 h
