| Product |
|---|
| Product type | Server |
| Manufacturer’s warranty | 3-year limited on-site service (see manufacturer's website for details) |
| Physical properties |
|---|
| Chassis type | Rack |
| Rack units | 1 U |
| Dimensions (W x H x D) | 440 x 43 x 773 mm |
| Processor |
|---|
| Server category | Dual processor |
| Processor family | Intel Xeon Silver |
| Processor model | Intel Xeon Silver 4509Y, 2.6 GHz |
| CPU cores | 8 |
| Clock speed | 2.6 GHz |
| CPUs (built-in / max.) | 1 / 2 |
| Storage |
|---|
| Compatible storage media | 6.4 cm (2.5") SAS, 6.4 cm (2.5") hot-swap |
| HDD | Optional |
| SSD | Optional |
| HDDs (built-in / max.) | 0 / 8 |
| Memory |
|---|
| RAM | 32 GB |
| RAM type | DDR5 ECC |
| RAM modules (built in / max.) | 1 / 32 |
| RAM (max.) | 8 TB |
| Drives |
|---|
| Drives | - |
| Connectivity |
|---|
| Connectors | 1 x RJ45 (management), 1 x USB 2.0 Type-A, 1 x VGA, 1 x USB 3.1 Type-A, 3 x USB 3.0 Type-A |
| Operating system |
|---|
| Operating system | - |
| Supported operating systems | Microsoft Windows Server 2019, Microsoft Windows Server 2022, Red Hat Enterprise Linux 8.8, Red Hat Enterprise Linux 8.9, Red Hat Enterprise Linux 9.2, Red Hat Enterprise Linux 9.3, SUSE Linux Enterprise Server 15 SP5, SUSE Linux Enterprise Server 15 Xen SP5, VMware ESXi 7.0 U3, VMware ESXi 8.0 U2 |
| Features |
|---|
| Motherboard chipset | Intel C741 |
| RAID controller | RAID 9350-8i |
| RAID levels | 0, 1, 10, 5 |
| Graphics |
|---|
| Graphics chip | ASPEED AST2600 |
| Performance |
|---|
| PSUs (built in / max.) | 1 / 2 |
| Effective power | 1100 W |
| Sustainability |
|---|
| Sustainability certifications | EPEAT Bronze (varies according to country) |
| Version |
|---|
| Version | Europe |
