| Product |
|---|
| Product type | Server |
| Manufacturer’s warranty | 3-year limited on-site service (see manufacturer's website for details) |
| Physical properties |
|---|
| Chassis type | Rack |
| Rack units | 1 U |
| Processor |
|---|
| Server category | Single processor |
| Processor family | Intel Xeon E |
| Processor model | Intel Xeon E-2234, 3.6 GHz |
| CPU cores | 4 |
| Clock speed | 3.4 GHz |
| CPUs (built-in / max.) | 1 / 1 |
| Storage |
|---|
| Compatible storage media | 6.4 cm (2.5") SATA |
| HDD | 1 TB |
| HDDs (built-in / max.) | 1 / 8 |
| Memory |
|---|
| RAM | 16 GB |
| RAM type | DDR4 ECC |
| RAM modules (built in / max.) | 1 / 4 |
| RAM (max.) | 64 GB |
| Drives |
|---|
| Drives | - |
| Connectivity |
|---|
| Network card | 2 x Gigabit Ethernet |
| Slots / bays (total) | 1 x PCIe x4, 1 x PCIe x8 |
| Connectors | 1 x VGA, 1 x serial |
| Operating system |
|---|
| Operating system | - |
| Supported operating systems | Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Microsoft Windows Server 2019, Red Hat Enterprise Linux 7.5, SUSE Linux Enterprise Server 15, VMware vSphere 6.5 (ESXi) Update 1 |
| Features |
|---|
| Motherboard chipset | Intel C246 |
| RAID controller | PERC H330 |
| Performance |
|---|
| PSUs (built in / max.) | 1 / 1 |
| Effective power | 350 W |
| Includes |
|---|
| Includes | Power cable, Tool-less rail kit |
