| Product |
|---|
| Product type | Industrial PC |
| Manufacturer’s warranty | 3-year on-site service (see manufacturer's website for details) |
| Processor |
|---|
| Processor family | Intel Core i7 |
| Processor model | Intel Core i7-8665UE, 1.7 GHz |
| Motherboard chipset | CPU-integrated |
| Memory |
|---|
| RAM | 16 GB |
| RAM type | DDR4 |
| RAM (max.) | 32 GB |
| RAM modules (built in / max.) | 1 / 2 |
| Graphics |
|---|
| Graphics | Intel UHD Graphics 620 |
| Storage |
|---|
| SSD | 512 GB |
| SSD form factor | 1 x 6.4 cm (2.5") SATA |
| Connectivity |
|---|
| Slots / bays (total) | 1 x 6.4 cm (2.5") bay, 1 x M.2 2280 PCIe |
| Network card | 2 x Gigabit Ethernet |
| Connectors | 1 x headphones, 1 x mic / headphones combo, 1 x DisplayPort, 1 x serial, 1 x HDMI, 2 x RJ45, 2 x USB 2.0 Type-A, 2 x DisplayPort, 2 x USB 3.0 Type-A, 4 x RS-232 |
| Wireless | Bluetooth, WLAN |
| Operating system |
|---|
| Operating system | Windows 10 IoT Enterprise |
| Drives |
|---|
| Drives | - |
| Security |
|---|
| Security | TPM 2.0 |
| Special features |
|---|
| Special features | NVMe |
| Physical properties |
|---|
| Chassis type | Micro housing |
| Dimensions (W x H x D) | 179 x 72 x 183 mm |
| Country variant |
|---|
| Country variant | United Kingdom |
